Hitachi TM3030 Plus - Page 349

7 - 55
Figure 7.18.1-4 During the Image Fix execution
The example of correction that uses the Image Fix is shown in Figure 7.18.1-5.
The shape of the hollow can be horizontally observed by correcting the tilted surface.
Before correction After correction
Figure 7.18.1-5 Example of Executing the Image Fix 3 points
