Assembly and Commissioning Instructions Servo amplifier D1-N
15.10.2015
The only difference is step 5.
“STABS test/tune”.
Figure 9.25: „Auto phase center“– „STABS test/tune“
VORSICHT!
The motor is energised and moved in the following step.
