Hiwin D1-N Series Assembly And Commissioning Instructions

180 / 183
Assembly and Commissioning Instructions Servo amplifier D1-N

15.10.2015
13.2
Item number for connector kit
Description
Content
Item no.
Connector kit CK4
D1N 09-18-36
1 × connector for main voltage X1
1 × connector for brake resistor X2
1 × connector for motor connection X3
1 × connector for control voltage. X4
1 × connector for I/O connection X6
2 × connector for safety function X7/X8
1 × connector for temperature sensor X9
2 × Sub-D-housing for feedback connection
2 × Sub-D connector 15pol. HD (male) for
connection at X10/X11
1 × Sub-D connector 15pol. HD (female) for
connection at X12
1 × hose clamp for shield connection at
motor connector (10 mm – 16 mm)
8-10-0800
Connector kit CK4
D1N 90
1 × connector for main voltage X1
1 × connector for brake resistor X2
1 × connector for motor connection X3
1 × connector for control voltage. X4
1 × connector for I/O connection X6
2 × connector for safety function X7/X8
1 × connector for temperature sensor X9
2 × Sub-D-housing for feedback connection
2 × Sub-D connector 15pol. HD (male) for
connection at X10/X11
1 × Sub-D connector 15pol. HD (female) for
connection at X12
1 × hose clamp for shield connection at
motor connector (10 mm – 16 mm)
8-10-0897
