Assembly and Commissioning Instructions Servo amplifier D1-N 15.10.2015
“Lightening” commissioning software
The D1-N drive amplifier is commissioned using the “Lightening” software. This
permits parameter setting and diagnosis using a standard PC. During operation,
any drive amplifier parameters can be recorded in real time. This greatly simplifies
the setting of controller parameters.
CPU 1.0 GHz or more
RAM 512 MB or more
Free hard disk memory At least 50 MB
Connections USB port
Operating system Win 2000, Win XP, Win 7
Monitor resolution At least 1024 × 768 pixels
Table 8.1: PC requirements
Installation of the software
To install the “Lightening” commissioning software, run the “Setup.exe” file.
The desired installation location can be changed under “Destination” (standard:
“C:\HIWIN\”). Press the “Start” button to start installation.
Figure 8.1: Installation software
