Page #55 background imageLoading...
Page #55 background image
Assembly and Commissioning Instructions Servo amplifier D1-N 15.10.2015
55 / 183
6.5.7
Protected cable routing
If short-circuits and/or cross-circuits may arise in conjunction with safety-related
signals and are not detected by upstream devices, protected routing in accordance
with ISO 13849-2 is needed.
In the event of unprotected routing, the cables for safety-related signals (SF1 and
SF2) may be damaged. If these damaged cables are connected to an external volt-
age, the safety function is no longer effective.
6.5.8
Data for maintenance plans and safety calculations
The maintenance plan for the machine and/or system must include checking the
safety function and this check must be performed at regular intervals. The interval
between the individual checks depends on the result of the risk analysis for the
entire system.
The minimum interval is 1 year (High Demand Mode according to IEC 61508). Use
the data listed below to produce your maintenance plan and for your safety calcu-
lations.
Lifetime of the safety function STO
(IEC 61508)
Years
20
SFF (IEC 61508)
Safe Failure Fraction
[%]
99.7
HFT (IEC 61508)
Hardware Fault Tolerance
Type A subsystem
1
Safety integraity level
IEC 61508:2010
IEC 62061:2010
SIL3
SILcl3
PL Performance Level (ISO 13849:2008)
e (Category 3)
MTTFd (ISO 13849-1)
Mean Time to Dangerous Failure
Years
1606 (for further
calculations, this
value is limited to
100 years)
DC (ISO 13849-1)
Diagnostic Coverage
[%]
99
PFH
d
(IEC 62061)
Probability of Dangerous Failure per Hour
[1/h]
3.60*10^-9
Table 6.5 Data for safety calculations
