Assembly and Commissioning Instructions Servo amplifier D1-N

15.10.2015
3.3
Guidelines and standards
EMC
EN 55011
EN 61000-6-2
EN 61800-3: 2004 (Category C3)
Emission:
IEC CISPR 11: 2009/A1: 2010
(Radiation & Conduction)
EN61000-3-2: 2006/A1: 2009/A2: 2009
(Harmonics)
EN61000-3-3: 2008 (Flicker)
EN61000-6-2: 2005
(Immunity for industrial environment)
Immunity:
IEC 61000-4-2: 2008 (ESD)
IEC 61000-4-3: 2006/A1: 2007/A2: 2010 (RF)
IEC 61000-4-4: 2004 (EFT)
IEC 61000-4-5: 2005 (Surge)
IEC 61000-4-6: 2008(RF)
IEC 61000-4-8: 2009 (MS)
Note: IEC 61000-4-11 & IEC 61000-2-4 &
IEC 61000-2-1 not evaluated.
Low-Voltage Directives
EN 61800-5-1
Machinery Directives
ISO 13849-1: 2006; PL e (Cat.3)
Functional safety
IEC 61508: 2010; SIL 3
IEC 62061: 2005; SILcl 3
IEC 61800-5-2(STO)
UL Standard
UL508C (E164620)
CSA Standards
C22.2 No. 14
Table 3.2: Guidelines and standards
3.4
Scope of supply
The scope of supply may vary depending on the configuration ordered. Before in-
stallation, please check whether all the ordered components have been supplied
and whether the goods are damaged. If the goods are damaged, please contact the
transport company immediately and document the damage.
Standard scope of delivery
• D1-N in the performance class ordered
• Plug connectors for all connections
• The latest documentation, commissioning software “Lightening” and other
valuable tools are free to download from www.hiwin.de
.
Accessories
Please refer to chapter 13 of this document or the current HHIWIN D1-N catalogue
for the extensive range of accessories. For more information, you can also visit
www.hiwin.de
.
