142 / 183
Assembly and Commissioning Instructions Servo amplifier D1-N
The “scope” is operated using the elements arranged along the right hand edge of
the screen:
: Switch scope on/off
: “Continuous paper” depiction mode
: Full-screen mode for one channel. Press several times to switch between
the active channels
: Adapt Y-axis scaling to window size
: Adapt Y-axis scaling dynamically to window size
: Adapt Y-axis scaling dynamically to window size, but only in the direction of
larger values.
: Start plot view
: Reset “scope” and delete current measurement curves
: Display all curves in a window.
: Start “Data collection” tool
: Select preset input variables
: Toggle the “Always to the fore” view
: Change number of channels
• The grid intensity can be set using the slider
• The time for the recording is set in the “time” field in the bottom right of
the screen
The “Plot View” function is provided for more detailed analysis of curve progress.
This tool does not work continuously like the scope function but is used to analyse
the curves recorded in the “Scope” or with the “Data Collector” (Record Window) at
a later point.
This tool also allows you to save and print recorded curves. To save and print, open
the “File” menu and select the desired option. You can save the curve as both an
image and in raw data format.
Start “Plot View” using the corresponding button in the scope function toolbar or
via the “Tools” menu in the “Lightening” interface.
