Assembly and Commissioning Instructions Servo amplifier D1-N 15.10.2015
E07 E07D.HOT Amplifier overtemperature Drive amplifier is too hot
Rectification of problem:
Check whether the area around the drive amplifier has sufficient ventila-
tion.
E08 E08M.HOT
Motor overtemperature
sensor activated
Motor overtemperature
sensor triggered
Rectification of problem:
Check whether the motor temperature sensor is correctly connected and
set. Check whether the motor parameters have been selected correctly.
Also check whether all necessary earthing has been correctly carried
out. For motor cables with integrated cables for the temperature sensor
in particular, poor or insufficient earthing may cause incorrect signals.
E09 E09UND.V Undervoltage detected Supply voltage is too low
Rectification of problem:
Check whether the main energy supply is correctly connected to the
drive amplifier and whether the energy supply voltage is within the drive
amplifier specification.
E10 E10V5ERR 5 V for encoder card fail
Error in encoder power
supply
Rectification of problem:
Switch off the drive amplifier and connect the encoder plug again. Check
the encoder cable for damage.
E11 E11PHINI Phase initialisation error
Error during commuta-
tion
Rectification of problem:
Check whether the motor parameters and encoder parameters in the
“Configuration center” are set correctly, whether the encoder signal is
free of errors, whether the motor load is too high, whether the friction is
too high and whether there are any obstacles blocking the motor.
E13 E13HAL.E Hall sensor error Hall sensor errors
Rectification of problem:
Check that the Hall sensor has been wired correctly and that it does not
signal an error.
E14 E14PHERR Hall phase check error
Digital Hall sensor elec-
trical angle
Careless mistake
Rectification of problem:
Check that the Hall sensor has been wired correctly and that it does not
signal an error.
