Assembly and Commissioning Instructions Servo amplifier D1-N 15.10.2015
The drive amplifier receives the nominal speed value via I/O interface
. Here the
nominal value can be supplied via the analogue input or via a digital input using
PWM.
Figure 8.21: “Configuration center” – velocity mode
The
is an area around the stationary point in which “small” signals in
the mV range do not trigger movement in order to compensate for any zero point
deviations.
Figure 8.22: Definition of “dead band”
