Pull out the small latch plate and the
latch plate from each holding slot in
the ceiling, and pull out the seat belt
to extend it.
Pull out the outer shoulder belts
from the holding slots. Both of the
third-row holding slots should only
be used when the seat belt is
detached.
Line up the triangle marks on the
small latch plate and anchor buckle
when reattaching the belt and buckle.
Tug on the seat belt to verify that
the detachable anchor is securely
latched. Make sure the seat belt is
not twisted.
Seats
164
SMALL LATCH PLATE
LATCH PLATE
TRIANGLE
MARKS
SMALL LATCH PLATE
Second row and third row center seats
ANCHOR BUCKLE
