Honda 2012 Pilot - Spare Tires; Trailer Lights

＋
Your vehicle is equipped with a
connector to install an optional trailer
lighting connector that mates with
your vehicle. You can get this
optional connector from your dealer.
Refer to the above illustration for
wiring information.
Trailer lights and equipment must
comply with federal, state, province/
territory, and local regulations.
Check trailer light requirements for
the areas where you plan to tow, and
use only equipment designed for
your vehicle.
When towing a trailer, we
recommend that you carry a full-size
spare wheel and tire for your vehicle
and trailer. When replacing the
compact spare with a full size spare,
remove the plastic spacer (see page
). Store the plastic spacer and
compact spare together. Reinstall
thespacerbeforeonceagainstowing
the compact spare.
See page for proper tire size,
page for how to store a full size
wheel and tire, and page for
information on changing a flat tire.
Remember to unhitch the trailer
before changing a flat. Ask your
trailer sales or rental agency where
and how to store the trailer’s spare
tire.
604
605
619
613
Trailer Lights
Spare Tires
Towing a Trailer
546
GROUND
(BLACK)
LEFT TURN SIGNAL
AND BRAKE LIGHTS
(RED)
TAILLIGHTS
(GREEN)
RIGHT TURN SIGNAL
AND BRAKE LIGHTS
(WHITE)
ELECTRIC BRAKE
(BROWN/WHITE)
BACK-UP LIGHTS
(YELLOW)
GROUND
(BLACK)
B CHARGE
(BLUE)
