This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
may rise to the upper zone. If it
reaches the red (hot) mark, pull
safely to the side of the road. For
instructions and precautions on
checking the engine’s cooling
system, see page .
This shows how much fuel you
have. It may show slightly more
or less than the actual amount.
623
Gauges
Temperature Gauge
Fuel Gauge
80
SPEEDOMETER
FUEL GAUGE
TEMPERATURE GAUGETACHOMETER
INFORMATION DISPLAYSELECT/RESET KNOB
SPEEDOMETER
TEMPERATURE GAUGE
SELECT/RESET KNOB
TACHOMETER
MULTI-INFORMATION DISPLAY
FUEL GAUGE
U.S. models are shown.
Except Touring models
On Touring models
Avoid driving with an extremely low
fuel level. Running out of fuel could
cause the engine to misfire, damaging
the catalytic converter.
11/08/01 08:30:10 31SZA630_087
