Open the hood.
Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it
about one-quarter turn
counterclockwise.
Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector onto
the new bulb.
Turn on the headlights to test the
new bulb.
Remove the socket by turning it
one-quarter turn counterclockwise.
If you need to change the bulbs on
the driver’s side, remove the front
end of the air intake duct by
pulling it out.
1.
2.
2.
3.
4.
5.
6.
CONTINUED
Replacing Front Turn Signal/
Parking and Side Marker Light
Bulbs
Lights
Maintenance
587
SOCKET
BULB
BULB
FRONT TURN SIGNAL/PARKING LIGHT
LOW BEAM HEADLIGHT
CONNECTOR
