Attach the tether strap hook to the
tether anchor, then tighten the
strap as instructed by the child
seat maker.
To install a LATCH-compatible child
seat in the center seating position on
the second row seat, use the center
lower anchors as shown above.
Follow step 1 through 4 as
described previously to secure the
child seat.
Lower the head restraint first.
Route the tether strap over the
head restraint and seat-back, then
attach the tether strap hook to the
anchor, making sure the strap is
not twisted.
Push and pull the child seat
forward and from side-to-side to
verify that it is secure.
Push and pull the child seat
forward and from side-to-side to
verify that it is secure.
Unlatch the detachable seat belt
anchor latch and retract the seat
belt all the way into the ceiling.
Place the latch plate and anchor
latch in their holding slots (see
page ).
6.
7.
2.
3.
4.
1.
163
Using the Center LATCH
Installing a Child Seat
50
11/08/01 08:24:47 31SZA630_057
