The vehicle’s fuses are located in
four fuse boxes.
The interior fuse box is underneath
the dashboard on the driver’s side.
Therearfuseboxislocatedatthe
left side of cargo area.
To open it, push the tabs as shown.
The primary under-hood fuse box is
locatedonthepassenger’sside.The
secondary fuse box is located next to
the battery.
Fuses
Taking Care of the Unexpected
629
UNDER-HOOD (SECONDARY)
UNDER-HOOD (PRIMARY)
TAB
TAB
REAR
LID
