In addition, the total weight of the
vehicle, all occupants, accessories,
cargo, and trailer tongue load must
not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR). Both
areonalabelonthedriver’s
doorjamb.
Example 1
Example 3
Example 2
Carrying Cargo
508
Passenger Weight
(150 lbs x 2 = 300 lbs)
(68kgx2=136kg)
Passenger Weight
(150 lbs x 4 = 600 lbs)
(68kgx4=272kg)
Passenger Weight
(150 lbs x 5 = 750 lbs)
(68kgx5=340kg)
Max Load (1,340 lbs)
(608 kg)
Max Load (1,340 lbs)
(608 kg)
Max Load (1,340 lbs)
(608 kg)
Cargo Weight
(1,040 lbs)
(472 kg)
Cargo Weight
(740 lbs)
(336 kg)
Cargo Weight
(590 lbs)
(268 kg)
