NORMAL OPERATION
Part. No. 2400M2501_6 Touchpoint Pro
110 Technical Handbook
13.5.4 Touchscreen Navigation
The icons in the navigation bar are used to navigate through the User Interface Software.
Key
System Status (Home)
Back
Inputs
Outputs
Figure 86. Touchscreen Navigation – Input and Output
