INTRODUCTION
Part. No. 2400M2501_6 Touchpoint Pro
15 Technical Handbook
3.3.3 SD Card
TPPR is supplied with an installed 4Gb SD card, which users may replace with a larger capacity if desired.
The SD card is used to store the event history of the system. TPPR logs all events and all changes to input readings.
Note: The SD Card should remain inserted during normal system operation as the motherboard has limited data storage
capacity.
3.3.4 USB Port
The USB Host port allows users to save reports, backup and restore configuration.
Note: USB devices must be formatted to FAT32 only; other file systems are not supported and will not work.
Note: The USB device is intended for maintenance and support operations only, and should be removed for normal use.
3.3.5 PC Configuration Software
This optional (downloadable) licensed software allows authorised users to configure some TPPR settings by using a remote
PC over an Ethernet connection. This is more efficient as you can use a larger screen and keyboard.
More information is available in a separate PC Configuration Operating Manual.
3.3.6 PC Operating Systems
Windows 7 is supported for use with PC Configuration software.
3.3.7 Webserver Software
This optional (pre-installed) licensed software allows users to remotely view live status, and analyse event history.
Authorised users can also acknowledge, inhibit and reset I/O channels.
The Webserver supports up to 5 concurrent web clients. More than 5 clients can connect but performance may degrade.
More information is available in a separate Webserver Operating Manual.
3.3.7.1 Supported Web Browsers
TPPR software is compatible with most current web browsers.
Honeywell will not be held liable for any loss or damage caused by any security breach, no matter how caused.
Windows XP is considered a high security risk and is not recommended.
