Honeywell touchpoint Pro Technical Handbook

CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
78 Technical Handbook
9.3.9 Threshold Alarm 2 Settings
Access Level: Engineer
Parameter Name
Default Setting
Value Range
Alarm 2 Enable
Enabled
Enabled / Disabled
Alarm 2 Level
Gas Range Min + NN*(Gas Range
Max - Gas Range Min)
Gas Range Min to Gas Range Max
Alarm 2 Trigger
Rising
Rising / Falling
Alarm 2 Latch
Latching
Non-Latching / Latching
Note: NN depends on sensor type selected, typically 0.50 (50%).
9.3.10 Threshold Alarm 3 Settings
Access Level: Engineer
Parameter Name
Default Setting
Value Range
Alarm 3 Enable
Enabled
Enabled / Disabled
Alarm3 Level
Gas Range Min + NN*(Gas Range
Max - Gas Range Min)
Gas Range Min to Gas Range Max
Alarm3 Trigger
Rising
Rising / Falling
Alarm3 Latch
Latching
Non-Latching / Latching
Note: NN depends on sensor type selected, typically 0.75 (75%).
9.3.11 Threshold Alarm Hysteresis
Access Level: Engineer
The hysteresis value will be applied to a channel coming out of an alarm condition, e.g. if the alarm level is 20 %FSD, and
hysteresis is set to 2 %, the alarm will not be cancelled until the reading has dropped below 18 %FSD.
Parameter Name
Default Setting
Minimum
Maximum
Threshold Alarm
Hysteresis
0.02*(Gas Range Max - Gas Range Min)
0
0.1*(Gas Range Max - Gas Range Min)

Honeywell touchpoint Pro Specifications

General

Brand	Honeywell
Model	touchpoint Pro
Category	Control Systems
Language	English
