Honeywell touchpoint Pro Technical Handbook

CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
77 Technical Handbook
9.3.6 Display Settings
Access Level: Administrator
Parameter Name
Default Setting
Value Range
Comment
Full Scale Exceeded
Enable
Enabled for mV
channels
Disabled for mA
channels
Enabled /
Disabled
The Full Scale Exceeded warning is set if the gas
reading rises above the configured full scale value and
it clears when the value falls below the full scale value.
The peak value may be seen in the Trend graph.
Note: If the gas value rises above the configured Over Range Warning setting, the Full Scale Exceeded warning is
replaced by the Over Range Warning. Refer to section 9.3.16
9.3.7 Suppression Settings
Access Level: Engineer
The gas concentration is set to zero when the gas concentration value received from the sensor is between the ‘Zero
suppression Positive’ and ‘Zero suppression Negative’ values.
Parameter Name
Default Setting
Minimum
Maximum
Zero Suppression
Positive
Depends on
sensor type
selected
Gas Range Min
Gas Range Min + 0.25*(Gas
Range Max – Gas Range Min)
Zero Suppression
Negative
Gas Range Min  0.25*(Gas
Range Max  Gas Range Min)
Gas Range Min
Note: Trend logging takes place when the values of an input channel change. The system will not log values while they
remain within the zero suppression limits.
Note: If a threshold alarm level is set within the zero suppression band, the alarm signal will not be generated.
9.3.8 Threshold Alarm 1 Settings
Access Level: Engineer
Parameter Name
Default Setting
Value Range
Alarm 1 Enable
Enabled
Enabled / Disabled
Alarm 1 Level
Gas Range Min + NN*(Gas Range
Max - Gas Range Min)
Gas Range Min to Gas Range Max
Alarm 1 Trigger
Rising
Rising / Falling
Alarm 1 Latch
Latching
Non-Latching / Latching
Note: NN depends on sensor type selected, typically 0.20 (20%).
