277

<ok/>

</rpc-reply>

Returning to the CLI

To return from XML view to the CLI, send the following close-session request:

<?xml version="1.0"?>

<close-session/>

</rpc>

When the device receives the close-session request, it sends the following response and returns to

CLI's user view:

<?xml version="1.0" encoding="UTF-8"?>

<rpc-reply message-id="101"

xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">

<ok/>

</rpc-reply>
