HPE FlexNetwork 5510 HI Series Network Management And Monitoring Configuration Guide

163
• Configure a cooperating remote destination group on the destination device.
• If intermediate devices exist, configure the following devices and ports to allow the remote
probe VLAN to pass through.
 Intermediate devices.
 Ports connected to the intermediate devices on the source and destinations devices.
When you configure Layer 2 remote port mirroring, follow these guidelines:
• For a mirrored packet to successfully arrive at the remote destination device, make sure its
VLAN ID is not removed or changed.
• Layer 2 remote port mirroring does not support using Layer 2 aggregate interfaces as source
ports or monitor ports.
• Do not enable MVRP on the devices or ports that allow the remote probe VLAN to pass through.
If MVRP is enabled, MVRP might register the remote probe VLAN with unexpected ports,
resulting in undesired copies. For more information about MVRP, see Layer 2—LAN Switching
Configuration Guide.
• As a best practice, configure devices in the order of the destination device, the intermediate
devices, and the source device.
Tasks at a glance
(Required.) Configuring a remote destination group on the destination device:
1. Creating a remote destination group
2. Configuring the monitor port for a remote destination group
3. Configuring the remote probe VLAN for a remote destination group
4.
Assigning the monitor port to the remote probe VLAN
(Required.) Configuring a remote source group on the source device:
5. Creating a remote source group
6. Configuring source ports for a remote source group
7. Configuring the egress port for a remote source group
8. Configuring the remote probe VLAN for a remote source group
Configuring a remote destination group on the destination
device
Creating a remote destination group
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2. Create a remote destination
group.
mirroring-group
group-id
remote-destination
By default, no remote destination
group exists on a device.
Configuring the monitor port for a remote destination group
To configure the monitor port for a mirroring group, use one of the following methods:
• Configure the monitor port for the mirroring group in system view.
• Assign a port to the mirroring group as the monitor port in interface view.
When you configure the monitor port for a remote destination group, follow these restrictions and
guidelines:
• Do not enable the spanning tree feature on the monitor port.
