Configuring the packet capture
Overview
The packet capture feature captures incoming packets that are to be forwarded in CPU. The feature
displays the captured packets in real time, and allows you to save the captured packets to a .pcap file
for future analysis.
The packet capture supports capture filters and display filters. You can use expressions to match
packets to capture or display.
Filter elements
A capture or display filter contains a keyword string or multiple keyword strings that are connected by
operators.
Keywords include the following types:
• Qualifiers—Fixed keyword strings. For example, you must use the ip qualifier to specify the
IPv4 protocol.
• Variables—Values supplied by users in the required format. For example, you can set an IP
address to 2.2.2.2 or any other valid values.
A variable must be modified by one or multiple qualifiers. For example, to capture any packets sent
from the host at 2.2.2.2, use the filter src host 2.2.2.2.
Operators include the following types:
• Logical operators—Perform logical operations, such as the AND operation.
• Arithmetic operators—Perform arithmetic operations, such as the ADD operation.
• Relational operators—Indicate the relation between keyword strings. For example, the =
operator indicates equality.
This document provides basic information about these elements. For more information about
capture and display filters, go to the following websites:
• http://wiki.wireshark.org/CaptureFilters.
• http://wiki.wireshark.org/DisplayFilters.
Capture filter keywords
Table 27 and Table 28 describe the qualifiers and variables for capture filters, respectively.
Table 27 Qualifiers for capture filters
Category
Description
Examples
Protocol
Matches a protocol.
If you do not specify a protocol
qualifier, the filter matches any
supported protocols.
• arp—Matches ARP.
• icmp—Matches ICMP.
• ip—Matches IPv4.
• ip6—Matches IPv6.
• tcp—Matches TCP.
• udp—Matches UDP.
Direction
Matches packets
based on its
source or destination location (an
IP address or port number).
• src—Matches the source
IP address
field.
• dst—Matches the destination IP address
