Configuring the collaboration feature
Collaboration is implemented by associating a reaction entry of an NQA operation with a track entry.
The reaction entry monitors the NQA operation. If the number of operation failures reaches the
specified threshold, the configured action is triggered.
To configure the collaboration feature:
1. Enter system view.
system-view
N/A
2.
Create an NQA operation
and enter NQA operation
view.
nqa
entry
admin-name
operation-tag
By default, n
exist.
3.
type and enter its view.
type
{
dhcp
|
dlsw
|
dns
|
ftp
|
http
|
icmp-echo
|
snmp
|
tcp
|
udp-echo
}
The collaboration feature is not
available for the ICMP jitter, path
jitter, UDP tracert, UDP jitter, or
voice,operations.
4. Configure a reaction entry.
reaction
item-number
checked-element
probe-fail
threshold-type consecutive
consecutive-occurrences
By default, no reaction entry is
configured.
You cannot modify the content of
an existing reaction entry.
5. Return to system view.
quit
N/A
6. Associate Track with NQA.
See
Configuration Guide.
N/A
7. Associate Track with an
application module.
See
Configuration Guide.
N/A
Configuring threshold monitoring
This feature allows you to monitor the NQA operation running status.
Threshold types
An NQA operation supports the following threshold types:
• average—If the average value for the monitored performance metric either exceeds the upper
threshold or goes below the lower threshold, a threshold violation occurs.
• accumulate—If the total number of times that the monitored performance metric is out of the
specified value range reaches or exceeds the specified threshold, a threshold violation occurs.
• consecutive—If the number of consecutive times that the monitored performance metric is out
of the specified value range reaches or exceeds the specified threshold, a threshold violation
occurs.
Threshold violations for the average or accumulate threshold type are determined on a per NQA
operation basis. The threshold violations for the consecutive type are determined from the time the
NQA operation starts.
Triggered actions
The following actions might be triggered:
• none—NQA displays results only on the terminal screen. It does not send traps to the NMS.
• trap-only—NQA displays results on the terminal screen, and meanwhile it sends traps to the
NMS.
