93
Table 18 Performance metrics and NQA operation types
Performance metric
NQA operation types that can gather the
metric
Probe duration
All NQA operation types except UDP jitter, UDP
tracert, path jitter, and voice
Number of probe failures
All NQA operation types except UDP jitter, UDP
tracert, path jitter, and voice
Round-trip time ICMP jitter, UDP jitter, and voice
Number of discarded packets ICMP jitter, UDP jitter, and voice
One-way jitter (source-to-
destination-to-source)
ICMP jitter, UDP jitter, and voice
One-way delay (source-to-
destination-to-source)
ICMP jitter, UDP jitter, and voice
Calculated Planning Impairment Factor (ICPIF) (see
"Configuring the voice operation")
Voice
Mean Opinion Scores (MOS) (see "Configuring the
voice operation")
Voice
NQA configuration task list
Configuring the NQA server
Required for TCP, UDP echo, UDP jitter, and
voice operations.
(Required.) Enabling the NQA client N/A
(Required.) Perform at least one of the following tasks:
• Configuring NQA operations on the NQA client
• Configuring NQA templates on the NQA client
When you configure
analyze network performance, the feature
that uses the template performs the NQA
operation.
Configuring the NQA server
To perform TCP, UDP echo, UDP jitter, and voice operations, you must enable the NQA server on the
destination device. The NQA server listens and responds to requests on the specified IP addresses
and ports.
You can configure multiple TCP or UDP listening services on an NQA server, where each
corresponds to a specific IP address and port number. The IP address and port number for a
listening service must be unique on the NQA server and match the configuration on the NQA client.
To configure the NQA server:
1. Enter system view.
system-view
N/A
2. Enable the NQA server.
nqa server enable
B
server is disabled.
3. Configure a
listening service.
• TCP listening service:
ip-address
The default ToS value is
0.
