[Agent] snmp-agent sys-info location telephone-closet,3rd-floor
# Enable notifications, specify the NMS at 1.1.1.2 as a trap destination, and set the username to
managev3user for the traps.
[Agent] snmp-agent trap enable
[Agent] snmp-agent target-host trap address udp-domain 1.1.1.2 params securityname
managev3user v3 privacy
2. Configure the SNMP NMS:
 Specify SNMPv3.
 Create the SNMPv3 user managev3user.
 Enable both authentication and privacy functions.
 Use SHA-1 for authentication and AES for encryption.
 Set the authentication key to 123456TESTauth&! and the privacy key to
123456TESTencr&!.
 Set the timeout timer and maximum number of retries.
For information about configuring the NMS, see the NMS manual.
NOTE:
The SNMP settings on the agent and the NMS must match.
3. Verify the configuration:
# Try to get the MTU value of NULL0 interface from the agent. The get attempt succeeds.
Send request to 1.1.1.1/161 ...
Protocol version: SNMPv3
Operation: Get
Request binding:
1: 1.3.6.1.2.1.2.2.1.4.135471
Response binding:
1: Oid=ifMtu.135471 Syntax=INT Value=1500
Get finished
# Try to get the device name from the agent. The get attempt fails because the NMS has no
access right to the node.
Send request to 1.1.1.1/161 ...
Protocol version: SNMPv3
Operation: Get
Request binding:
1: 1.3.6.1.2.1.1.5.0
Response binding:
1: Oid=sysName.0 Syntax=noSuchObject Value=NULL
Get finished
# Execute the shutdown or undo shutdown command on an idle interface on the agent. You
can see the link state change traps on the NMS:
1.1.1.1/3374 V3 Trap = linkdown
SNMP Version = V3
Community = managev3user
Command = Trap
1.1.1.1/3374 V3 Trap = linkup
SNMP Version = V3
Community = managev3user
