HPE FlexNetwork 5510 HI Series Mpls Configuration Guide

66
Configuring the affinity attribute for an MPLS TE tunnel
The associations between the link attribute and the affinity attribute might vary by vendor. To ensure
the successful establishment of a tunnel between two devices from different vendors, correctly
configure their respective link attribute and affinity attribute.
To configure the affinity attribute for an MPLS TE tunnel:
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2.
Enter MPLS TE tunnel
interface view.
interface tunnel
tunnel-number
[
mode mpls-te
]
N/A
3. Configure an affinity for the
MPLS TE tunnel.
mpls te affinity-attribute
attribute-value [
mask
mask-value ]
By default, t
he affinity is
0x00000000, and the mask is
0x00000000. The default affinity
matches all link attributes.
Configuring a setup priority and a holding priority for an MPLS TE tunnel
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2.
Enter MPLS TE tunnel
interface view.
interface tunnel
tunnel-number
[
mode mpls-te
]
N/A
3.
Configure a setup priority
and a holding priority for the
MPLS TE tunnel.
mpls te priority
setup-priority
[ hold-priority ]
By default, the setup priority and
the holding priority are both 7 for
an MPLS TE tunnel.
Configuring an explicit path for an MPLS TE tunnel
An explicit path is a set of nodes. The relationship between any two neighboring nodes on an explicit
path can be either strict or loose.
• Strict—The two nodes must be directly connected.
• Loose—The two nodes can have devices in between.
When establishing an MPLS TE tunnel between areas or ASs, you must do the following:
• Use a loose explicit path.
• Specify the ABR or ASBR as the next hop of the path.
• Make sure the tunnel's ingress node and the ABR or ASBR can reach each other.
To configure an explicit path for a MPLS TE tunnel:
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2. Create an explicit path and
enter its view.
explicit-path
path-name
By default, no explicit path exists
on the device.
3. Enable the explicit path.
undo disable
By default, an explicit path is
enabled.
4. Add or modify a node in the
explicit path.
nexthop
[
index
index-number ]
ip-address [
exclude
|
include
[
loose
|
strict
] ]
By default, an explicit path does
not include any node.
You can specify the
include
keyword to have the CRLSP
traverse the specified node or the
exclude
keyword to have the
