10. Position Edit

124

114

Transmit position data to the controller by pressing

the WRT key.

The Position No. moves to 12.

* If you change the screen with the PAGE UP ·

PAGE DOWN or ESC keys before transmitting

the data, the input data will be invalid.

Finish the position data input by teaching.

Press the ESC key.
