12. Coordinate System Data Editing of the SCARA Axis

: 1 axis – 4 axis of the X-SEL-KX and PX/QX controller

184

169

To write the data in Flash ROM, press the F1 (Yes)

key.

If not, press the F2 (No) key.

The message “Please wait…” flashes during Flash

ROM writing.

* Never turn off the power to the Controller at this

time.

Flash ROM writing is completed.

Return to the edit mode screen with the ESC key.
