187

13. Symbol Edit

(Excluding the positioner mode of the SSEL, ASEL and PSEL controller.)

187

172

Press

several times to display “n.”

Press the return key.

Press the

(10 keys) several times to display “t.”

Then press the return key.

The F1 key area display changes to Num by

pressing the F1 (Alph) key. It becomes a numerical

input.

Input 5 by using the 10 keys.

Press the return key to determine the symbol name.

Numerical input
