IAI SEL User Manual

191
13. Symbol Edit (Excluding the positioner mode of the SSEL, ASEL and PSEL controller.)
191
176
(3) Program
Select the F3 (Prog) key on the symbol edit item screen.
Mode Transition:
Program No. Symbol Edit Screen
(4) Position
Select the F4 (Posi) key on the symbol edit item screen.
Mode Transition:
Position No. Symbol Edit Screen
(5) Input Port
Select the F1 (In) key on the symbol edit item screen.
Mode Transition:
Input Port No. Symbol Edit Screen
Input program No. by the PAGE UP · PAGE DOWN keys
or 10 ke
y
s.
Input alphabet and number.
Input alphabet and number.
Input position No. by the PAGE UP · PAGE DOWN keys
or 10 ke
y
s.
Input alphabet and number.
Input input port No. by the PAGE UP · PAGE DOWN
ke
y
s or 10 ke
y
s.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
