194

13. Symbol Edit

(Excluding the positioner mode of the SSEL, ASEL and PSEL controller.)

194

179

(11) All Clear

Select the F4 (Aclr) key on the symbol edit item screen.

Mode Transition: Edit–Sym-Aclr

All Clear Screen

To clear all symbols, select the Yes key.

To cancel them, select the No key.

If the Yes key is selected, all the symbol data will be

cleared and “Complete!” will be displayed.
