13. Symbol Edit (Excluding the positioner mode of the SSEL, ASEL and PSEL controller.)
193
178
(9) Tag
Select the F1 (Tag) key on the symbol edit item screen.
Mode Transition:
Tag No. Symbol Edit Screen
(10) Subroutine
Select the F2 (SubR) key on the symbol edit item screen.
Mode flow:
Subroutine No. Symbol Edit Screen
Input program No. since tag No. is in
the local area.
Input program No. since subroutine
No. is in the local area.
Input alphabet and number.
Input tag No. by the PAGE UP · PAGE DOWN keys or 10
ke
y
s.
Input subroutine No. by the PAGE UP·PAGE DOWN
ke
y
s or 10 ke
y
s.
Input alphabet and number.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
