15. Monitor

204

189

(2) Servo status

Mode Transition:

Axis No. can be switched with the PAGE UP ·

PAGE DOWN keys.

Servo ON axis in use

Axis No.

Homing

Servo

Moving Command Normal End

Over Push Limit Error

(System Reservation)
