15. Monitor

205

190

(3) Sensor Input Status

Mode Transition:

Orthogonal axis

SCARA axis

Axis No. can be switched with the PAGE UP

· PAGE DOWN keys.

Axis No.

(System Reservation)

Creep Sensor

Overrun Sensor

Home Sensor

Axis No.

(System Reservation)
