15. Monitor

206

191

(4) Encoder Status

Mode Transition:

Axis No. can be switched with the PAGE UP

· PAGE DOWN keys.

Axis No.

Over Speed

Full Absolute Status

Count Error

Multi-rotation Error

Battery Error

Battery Alarm
