15. Monitor

207

192

(5) Axis Related Error

Mode Transition:

Axis No. can be switched with the PAGE UP ·

PAGE DOWN keys.

xis No.

Program No.

xis No.

Information 1

Information 2

Error Code

Step No.

Position No.

Information 3

Information 4

Error code Axis No.

Time from the last software reset or power

reconnection to error occurrence
