16. Controller

230

③

Simple ABS Unit Status Initialization

Press the F1 (OK) key.

④

Clear Complete Excitation Detection

Status

Press the F1 (OK) key.

⑤

Servo ON

Press the F1 (OK) key.

⑥

Home return

Press the F1 (OK) key.

⑦

Absolute Reset

Press the F1 (OK) key.

⑧

Confirm Reset Complete of Absolute

Press the F1 (OK) key.
