IAI SEL User Manual

16. Controller
231
Return to the axis No. input screen.
To execute absolute reset on other axes, input axis
No. here and press the F1 (OK) key. Repeat ①~⑧.
To finish absolute reset, press the ESC key.
Move to the software reset screen.
Press F1 (Yes) key to execute software reset.
After the software reset, return to the mode selection
screen.
sba eht rof lla s’tahT olute reset operation.
teser ot erus eb ,teser etulosba gnitucexe retfA
software or reconnect the power.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
