3. Connection to Controller

8

9

X-SEL-PX (QX) Type Controller

▪ Set the teaching pendant type selection switch of the X-SEL-PX type to the left.

SCARA

Mode Switch

Emergency

Stop Switch

Enable

Switch

Teaching Pendant

Type Selection Switch

(PX only)

Caution

2-axis

1-axis
