IAI SEL User Manual

273
17. Gateway Function Associated
273
(3) Actuator Movement
①
Jogging Operation
Perform the jogging operation of the RC actuator.
The actuator applicable to this operation is one with a single axis.
Place the cursor on the Axis No. and select the RC actuator using the ten-key or
.
Current Position
Turn the servo-motor ON.
Press the or key to move the actuator to any
position. ( “ + ” means the movement to the plus
direction on the coordinates and “ - ” means the
movement to the minus direction on the coordinates).

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
