IAI SEL User Manual

* Supplement
302
242
Controller no connection error. Communications cannot be established or an unsupported controller is connected. The probable causes are as follows: ① It is a communication failure due to a break in or noise from the communication line. ② The communication baud rate of the controller is not supported by the teaching pendant.
(The failure may be resolved by the controller power reconnection.)
③ The model not supported by the teaching pendant is connected. (Refer to Support Models.) The EMERGENCY STOP button of the teaching pendant is pressed. Non-supported controller is connected.
CTL Not Connected Emergency Stop Non-supported CTL is connected
DEE
DEF
DF0

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
