IAI SEL User Manual

7. Simple Operation Procedure
65
55
Return to the position edit screen by pressing the
ESC key.
The edit mode screen will be appear by pressing the
ESC key once more.
The Flash ROM writing screen will be appear by
pressing the ESC key again.
To write the data to Flash ROM, press the F1 (Yes)
key.
If not, press the F2 (No) key.
During Flash ROM writing, “Please Wait....” blinks.
* Never shut off the power to the controller
during Flash ROM writing.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
