7. Simple Operation Procedure
64
54
Transmit the data with the WRT key and move to
position No. 6.
⑥
Data input for the sixth point
Input 0 for the first axis position data and press the
return key.
Input 50 for the second axis position data and press
the return key.
Transmit the data with the WRT key and move to
position No.7.
Finish editing, then write the data to Flash ROM.
The cursor moves to the position No. by pressing
ESC key.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
