IAI SEL User Manual

7. Simple Operation Procedure
76
66
Select the F1 key (Mdfy) on the program edit and
new creation screen.
Change to the program edit and new creation
screen. Press the return key once and position the
cursor at the step No.
Insert a 1 line step between step No. 2 and 3. Input 3
by pressing “3” or display 3 by pressing the PAGE
UP key twice.
Select the F1 key (Ins).
I, Insert of I will be displayed after step No. 3.
Display “TAG” by using the
in the 10 key, SF
key or key.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
