IAI SEL User Manual

7. Simple Operation Procedure
77
67
Select the F1 key (TAG) and press the return key.
Input 1 into operation 1 and press the return key.
Transmit the data to the controller by pressing the
WRT key.
* If you change the screen with the PAGE UP ·
PAGE DOWN or ESC keys before transmitting
the data, the input data will be invalid.
Display the step No. 4 screen by pressing the ESC
key twice.
Delete the “MOVL 6.” Input 9 for the step No. by
pressing the 9 key directly to the same cursor
location or display the “MOVL 6” by pressing PAGE
UP key 5 times.
(The cursor is located at step No.9.)

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
