4 Write-protect switch
5 Power connector
6 USB connector
ROLSOS601-0
4
Figure 44. Front view of the RXD Drive Assembly
ROLSOS602-0
5
6
Figure 45. Rear view of the RDX Drive Docking Station
108 7226 Storage Device Enclosure Setup, Operator and Service Guide
