IBM 7226 Service Manual

Flowchart for IBM Power Systems with Linux Operating System
ROLSOS901-0
Step 1
Does the
7226
power up?
Shut the system down
and power off
Shut the system down
and power off
Step 2
Electrical outlet
OK?
Step 3
Power cable
OK?
Step 6
Is the enclosure
fan failing?
Step 23
Do messages specify a
replacement FRU or
service action?
Step 21
Verify devices are
configured properly
Step 8
Any visual
problem?
Step 12
Any visual
problem?
Step 9
Enclosure Power
OK?
Remove cover and
prepare unit
Remove cover and
prepare unit
Use different
electrical outlet
Replace
power cable
Fix problem and
return to Step 1
Fix problem and
return to Step 1
Replace FRU/contact
service personnel
yes
yes
no
yes
yes
yes
yes
yes
no
no
no
no
no
no
no
Step 7
Did drive
complete
POST?
yes
no
yes
Step 4
Any visual
problem?
Step 5
Drives OK?
Fix problem and
return to Step 1
yes
no
no
Replace drive
and return to Step 1
Replace
enclosure
yes
Proceed to Step 6
Step 10
Drives power
up normal?
yes
no
Replace failing
drive and
return to Step 1
Shut the system down
and power off
Step 11
Media
OK?
Remove cover and
prepare unit
no
yes
Replace media
and return to Step 1
Replace enclosure
and return to Step 1
Go to Step 16
on page 145
Step 24
Is an AIX stand alone
diagnostics CD
available?
Contact service
personnel
Step 22
Check /var/log/messages
for related error messages
no
yes
Step 14
SAS/USB/Fibre
Channel Interface
Assembly
OK?
yes
yes
no
no
Replace USB, SAS or
Fibre Channel cable
and return to Step 1
Replace Interface
Assembly and
return to Step 1
Step 13
External USB, SAS
and Fibre Channel
Cables OK?
Figure 49. Flowchart for IBM Power Systems with Linux Operating System
Chapter 10. Troubleshooting 121
