Step 15 (IBM Power System with AIX Operating System Only)
This step verifies that the 7226 storage enclosure has been properly configured to
the IBM Power System with AIX Operating System.
Check the configuration of the 7226 storage enclosure to the host system software
by doing the following:
1. Log into the host system (AIX operating system).
Note: You must have root authority to install or remove the 7226 storage
enclosure from the system. To obtain root authority, see your system
administrator.
2. To see the installed SAS device status, at the system prompt, type
lsdev -Cs sas
and press Enter. The command lists all of the SAS devices that are connected to
the host system. Figure 51 shows an example of the screen that displays. The
screen lists:
1 Device name 3 System address
2 Device Status 4 Description of the device
3. To see the installed SATA device status, at the system prompt, type
lsdev -Cs sata
and press Enter. The command lists all of the SATA devices that are connected
to the host system. Figure 52 shows an example of the screen that displays. The
screen lists:
1 Device name 3 System address
2 Device Status 4 Description of the device
4. To see the installed USB device status, at the system prompt, type
#lsdev
and press Enter. The command lists all of the devices that are connected to the
host system. Figure 53 on page 130 shows an example of the screen that
displays. The screen lists:
rmt0 Available 03-08-00 SAS 4mm Tape Drive
rmt1 Available 03-08-00 SAS 4mm Tape Drive
rmt2 Available 03-08-00 SAS 4mm Tape Drive
RLHSO511-0
Figure 51. Screen Display of SAS Devices Attached to the host system
cd0 Available 03-08-00 SATA DVD-RAM Drive
RLHSO512-0
Figure 52. Screen Display of SATA Devices Attached to the host system
Chapter 10. Troubleshooting 129
