Specifications
Table 2. Specifications for the 7226 Model 1U3 storage enclosure
Physical Specifications
Width 438 mm (17.5 in)
480 mm (18.9 in.) Including Right and Left Latch
assemblies
Depth 454 mm (17.9 in.)
Height 43 mm (1.69 in.)
Weight 5.1 kg (10.2 lbs) Empty Enclosure
7.1 kg (15.6 lbs) Typical Configuration
Power Specifications
kVA 0.047 @ 120 V AC
V AC 100 to 240
Hertz 50 to 60
Btu Maximum (watts) 478 Btu/hr (140 watts) @ 240 V AC
Power Factor 0.75 to 0.9
Altitude Maximum 3058 m (10000 ft)
Performance Specifications
Dependant on device, media type, and configuration.
Recommended Environment
Environmental Factor Operating Non-operating
Temperature 10 to 40°C
(50 to 104°F)
-40 to 65°C
(-40 to 149°F)
Relative Humidity
(non-condensing)
20 to 80%
non-condensing
5 to 95% (excluding rain)
Maximum Wet Bulb 26°C
(79°F)
29°C
(84°F)
Chapter 1. General Information 7
